Airtight Self-Seal Ducting
Please note most of our hoods have a motor exhaust of 150mm. We supply reducer collars should you need to use smaller ducting.
We highly recommend using the largest possible size ducting on every installation to maximise air flow.
Please check each product specification guide to determine what size duct you require.
220mm x 90mm 6" 90° Vertical Elbow
220mm x 90mm 90° Vertical Elbow
This part is used for connecting two 220mm x 90mm flat ducting pipes to each other at a 90° vertical bend ensuring smooth airflow is achieved through corners.
This patented push fit system requires no ugly ducting tape and ensures a airtight seal between coupling.
This elbow is part of our 6" Airtight range, commonly referred to as 6 inch ducting due to the round pipe being 150mm wide. This system includes both 220mm x 90mm flat ducting and 150mm round ducting as they both have similar airflow rates. We supply adapters should you need to switch between these sizes:
This is part number 7 from the quick link chart.
150mm (6") Airtight Kitchen Extractor Ducting Quick Link
220mm x 90mm (6") 90° Vertical Ducting Elbow
- Brand: Luxair Cooker Hoods Limited
- Product Code: 150-BEND-RECT-VERTICAL
- Ex Tax: £9.96
